(PT. 5032) Extra Large Flange Mount 130Kg (M10)
Click on thumbnail(s) to enlarge

(PT. 5032) Extra Large Flange Mount 130Kg (M10)

Item Code: FM200/4S Price: £32.49 + VAT

***Click here toVisit our New Online Shop for more sizes***


Flanged Mountings give high levels of deflection, providing excellent levels of vibration reduction and shock absorption both in vertical & horizontal planes. Low costs & easy to install. Stainless Steel metals and Oil Resistant / High Temperature rubbers available on request.

Applications include:- Pumps, Fans, Compressors, Vibratory Screens, and Processing Equipment etc.


  • Flanged Rubber Mount
  • High Quality Natural Rubber
  • Ideal for static applications
  • 40 Shore rubber hardness
  • Maximum Load 130Kg
  • 10mm Deflection


  •
