(PT. 12001) 20 x 25 Female Female Bobbin M6 Max Load 12.6Kg
Click on thumbnail(s) to enlarge

(PT. 12001) 20 x 25 Female Female Bobbin M6 Max Load 12.6Kg

Item Code: 2025FF06-60 Price: £1.89 + VAT

***Click here to Visit our New Online Shop for more sizes***


Bobbin Mounts are a low cost solution to reducing vibration & shock. They can be used in either Compression or Shear.

Applications include: General Purpose mountings, popular in a wide range of applications & industries including Diesel Engines, Generator Sets, Instruments, Industrial Machinery & Equipment.


  • 20mm Diameter x 25mm Height
  • Female Female bobbin
  • M6 x 06 threaded holes both ends
  • 60 Shore rubber hardness
  • Max Compression Load 12.6Kg
  • Deflection at Max Load 2.2mm


    •
