(PT. 12003) 30 x 30 Female Female Bobbin M8 Max Load 40Kg
Click on thumbnail(s) to enlarge

(PT. 12003) 30 x 30 Female Female Bobbin M8 Max Load 40Kg

Item Code: 3030FF08-70 M8 Price: £3.59 + VAT

***Click here to Visit our New Online Shop for more sizes***


Bobbin Mounts are a low cost solution to reducing vibration & shock. They can be used in either Compression or Shear.

Applications include: General Purpose mountings, popular in a wide range of applications & industries including Diesel Engines, Generator Sets, Instruments, Industrial Machinery & Equipment.


  • 30mm Diameter x 30mm Height
  • Female Female bobbin
  • M8 x 08 threaded holes both ends
  • 70 Shore rubber hardness
  • Max Compression Load 40Kg
  • Deflection at Max Load 2.6mm
  • Sorry, this item is temporarily out of stock.
